Single Mode ST To SC Male To Female Attenuator For Fiber Optic
1. Product Overview:
Geehe offers high-quality fixed in-line fiber optic attenuators
ranging from 1-30dB. Available in FC/APC, SC/APC, LC, and ST; these
attenuators feature a male connector at the front end and a female
socket adaptor at the back.
Each attenuator is made with continuous light-absorbing and
metal-ion doped fiber which provides excellent environmental
stability and low back reflection. With this simple yet reliable
structure, attenuators are added to the optical patch without extra
connectors.
2. Optical Cable Adaptor Feature and Benefits:
- Converts Cable Tester’s FC Connector to an SC Connector
- Ideal for cable installers or anyone else working in telecom or LAN
environments
- Perfect for 62.5/125 multimode cable testing
- Included dust caps keep connectors clean
- Insertion Loss: 0.20dB , Mating Durability: 500
- All metal construction for long life
- Hybrid adapter accommodates both Multimode and Single mode.
3. Fiber Optic Adapter Applications:
- Datacenter
- Telecommunication networks
- Premise installations
- LAN and WAN
- FTTX
- Broadband network
4. Optic Adapter Specification & Technology Parameters:
| Item | Value | Unit |
| Sleeve Material | Ceramic | / |
| Insertion Loss | Male | Typ. | ≤ 0.5 | dB |
| Min. | ≤ 0.2 | dB |
| Female | Typ. | ≤ 0.3 | dB |
| Min. | ≤ 0.2 | dB |
| Return Loss | UPC | ≥50 | dB |
| APC | ≥60 | dB |
| PC | ≥35 | dB |
| Insertion Loss Max. | 0.2 | dB |
| ∆ IL | Uniformity | ＜0.2 | dB |
| Durability (1000 times) | ＜0.3 | dB |
| Proof Test | 40N,10 minute | N |
| Insertion And Withdrawal Force | ≤19.6N | N |
| Operating Temperature | -25~+70 | ℃ |
| Storage Temperature | -25~+70 | ℃ |
| Protocol Standards | IEC60874-10/61300/TIA/EIA568 |
5. Ordering Information:
| OFC | -X | -XX | -XX | -XX | -X | -X |
| S: Simplex
D: Duplex | SC
FC
ST
LC
MU | APC
UPC
PC | Z: Zirconia ceramic P: Phosphor Bronze | W: With Flange
N: No Flange | W: With shutter
N: No shutter |
| Fiber Mode | Connector Type | Connector Type | Sleeve | Flange Type | Shutter Type |
6.More Options Optic Adapters:
7. Wuhan Geehe Comm Service:
1) High Environmental Stability
Low insertion loss, low polarization dependent loss, low back
reflection, and good uniformity
2) Compact Structure
Small size, it can be directly installed in a variety of transfer
box and just take up little space
3) Strict Quality Control
We guarantee that every product to the hands of customers is
subject to stringent testing standards
4) ISO9001:2015 Certification by SGS
All products have passed ISO9001:2015 System and reached Telcordia
GR-326-Core
