Small Size 1×4 Steel Tube 850nm 1550nm Single Mode Fiber Optic
Splitter
Optic Splitter Basic Information :
Optical Splitter 1×4 Steel Tube Single Mode Fiber Optic Splitter
with SC/APC connectors is a widely used Fiber splitter. You can use
it to be inserted into an LGX box or ABS box. This optical splitter
can be also coming with other fiber connectors SC LC ST etc.
Usually, Dual window 1310/1550nm are available in stock.
The Single-mode Optic-fiber splitters can divide the optical
signals and then re-distribute the light power.
Optic Splitter Features& Benefits:
- Free Optical Splitter 1x4 FBT fiber splitter Sample
- Single, Dual, Three Wavelengths for Options
- SC FC LC ST or other Customized Connectors
- Low Insertion Loss & High Return Loss
- Plastic Module Package for Safe Protection
- Different Fiber Cable Diameters Supplied
- Excellent Environmental & Mechanical Stability
- Excellent Mechanical, Small Size
- Low insertion loss and low Polarization Dependent loss
Application&Standard:
- Fiber optic equipment & systems
- CATV networks
- Data communications
- Passive Optical Network
Specification& parameters
| Parameter | 1x4 | 1x8 | 1x16 | 1x32 | 1x64 | 2x4 | 2x8 | 2x16 | 2x32 |
| Operating Wavelength(nm) | 1260~1650 |
| Port Wavelength Range (nm) | 1310 ±20,1490 ±10 and 1550 ±20 |
| Insertion Loss @1310nm/1550nm | 7.1 | 10.5 | 13.6 | 16.8 | 20.5 | 7.4 | 10.8 | 14.5 | 17.5 |
| Uniformity (dB) | 0.5 | 0.8 | 1 | 1.2 | 1.8 | 1.2 | 1.5 | 1.8 | 2 |
| PDL @ 1310/1550 nm (dB) | ≤0.3 |
| Return Loss@ 1310/1551 nm (dB) | ≤-55 |
| Input Power (mW) | 250max |
| Operating Temperature (℃) | -40~+85℃ |
| Storage Temperature (℃) | -40~+85℃ |
| Fiber Type | Corning G657A1 |
Optic Splitter Package Dimensions:
| WxHxD(mm) | Port |
| 60x4x4 | 1x4 | 1x8 | 2x4 | 2x8 |
| 60x12x4 | 1x16 | 2x16 |
| 80x12x6 | 1x32 | 2x32 |
| 100x40x6 | 1x64 |
Ordering Information:
| PLC | AAA | B | CC | D | EE | FF | GG |
| 104=1x4 108=1x8 …… 164=1x64 204=2x4 …… 232=2x32 | 1=900µm loose | 05=0.5m 10=1.0m 15=1.5m 20=2.5m | 1=900µm loose | 05=0.5m 10=1.0m 15=1.5m 20=2.5m | SA=SC/APC SU=SC/UPC LA=LC/APC LC=LC/UPC 00:No connector | SA=SC/APC SU=SC/UPC LA=LC/APC LC=LC/UPC 00:No connector |
| Configuration | Input Fiber Type | Input Fiber Length | Output Fiber Length | Output Fiber | Input Connector | Output Connector |
