FTTH Bend Insensitive Multimode Fiber Patch Cable Yellow SC To FC
Fiber Connector
1.Basic Introduction:
Our extensive selection of bend unfeeling fiber includes the Yellow
10 Meter SC to FC Multimode duplex fiber optic patch cable shown
here. The fiber optic patch cables feature OFNR (Riser rated)
jackets along with SC and FC style connectors.
These cables are great for high-speed trunks between servers,
switches, storage, and fiber-optic switching equipment in busy
datacenters. Custom lengths, connector combinations, and polishes
are available.
Improve network reliability with our low-loss bend optimized fiber
cables, which remove the hassle of searching for the bend that's
bringing down your network.
2. SC To FC Patch Cord Benefit & Features:
- Connectors utilize a PC polish
- OFNR (Riser-Rated) jacket complies with stringent building codes
- Used to connect patch panels and/or network devices that utilize FC
or SC style connectors and require OM2 50/125 multimode cabling
- A/B Markers are included for each fiber which identity transmit and
receive ports ensuring correct system connector
- Ceramic ferrules provide precise alignment
- Meets Telecordia-GR-326-CORE specifications
- Free SC-FC fiber optic patch cable sample
- Screw-on FC connectors for easy installation
3.Fiber Optic Patch Cord Applications:
- FTTX
- Industrial Network
- High-speed data transmission broadband systems
- Telecommunication optical transmission network
- Optical access network(OAN)
- Local Area Network (LAN)
4.Specification&Technology Parameter
| Parameters | Value |
| Connector Type | LC/UPC,FC/UPC,SC/UPC,MU/UPC |
| Center Wavelength(nm) | 1310 or 1550,980 or 1060,850,780 |
| Max.Insertion Loss(dB) | 0.3 |
| Min.Extinction Ratio(dB) | 23 |
| Min.Return Loss(UPC) (dB) | 50 |
| Min.Return Loss(APC) (dB) | 60 |
| Key Orientation | Slow Axis |
| Axis Alignment(deg) | ±3 |
| Operating Temperature(℃) | -20~+70 |
| Storage Temperature(℃) | -40~+85 |
| FIber Type | PM Panda Fiber |
* For Device with connector.IL is 0.3dB higher,RL is 5dB lower,ER
is 2dB lower.
* The default connector key is aligned to the slow axis.
5.SC&FC Connector Specification& Technology Parameter:
| Parameter | Unit | Index |
| End-Face Type | | PC | UPC | APC |
| IL | dB | SM: ≤0.3；MM ≤0.1 |
| Repeatability | dB | ≤0.1 |
| interchangeability | dB | ≤0.2 |
| RL | SM | dB | ≥50 | ≥50 | ≥50 |
| MM | dB | ≥36(Without APC connector) |
| Mating Times | | ＞1000 |
| Operating Temperature | ℃ | -40~ +80 |
6.SC Patch Cord Ordering Information:
| OFC | -X | -XX | -XX | -XX | -X | -X |
| S: Simplex
D: Duplex | SA:SC/APC SC:SC/UPC SP:SC/PC | SA:SC/APC SC:SC/UPC SP:SC/PC | 09:0.9mm 20:2.0mm 30:3.0mm | 0:G652D 1:G657A 2:50/125 3:62.5/125 4:others | 0.5:0.5m
1.0:1.5m
10:10.0m |
| Fiber Mode | Connector Type | Connector Type | Cable Diameter | Flange Type | Fiber Length |
* EX: OFC-S-SC-SC-09-1-0.5
7.FC Patch Cord Ordering Information:
| OFC | -X | -XX | -XX | -XX | -X | -X |
| S: Simplex
D: Duplex | FA:FC/APC FC:FC/UPC FP:FC/PC | FA:FC/APC FC:FC/UPC FP:FC/PC | 09:0.9mm 20:2.0mm 30:3.0mm | 0:G652D 1:G657A 2:50/125 3:62.5/125 4:others | 0.5:0.5m
1.0:1.5m
10:10.0m |
| Fiber Mode | Connector Type | Connector Type | Cable Diameter | Flange Type | Fiber Length
|
EX: OFC-S-FA-FC-09-1-0.5
