1m MTRJ-MTRJ 62.5/125 OM1 Dulpex Orange Mulit Mode mode PVC Fiber
Optic Cable
1.Basic Introduction:
With MTRJ to MTRJ termination, this high-quality fiber optic patch
cable is specifically designed for ethernet, multimedia, or
communication applications.
The MTRJ connector features an easy-to-use latch-type design
similar to the RJ connector on a Cat5 patch cable and is half the
size of the SC connector. With its small footprint design, the MTRJ
connector can increase the port density.
The patented injection molding process provides each connection
greater durability in resisting pulls, strains, and impacts from
cabling install.
Each cable is 100% optically inspected and tested for insertion
loss before you receive it.
2.Patch Cord Benefit & Features:
- MTRJ Connector Dimensions: 7.5mm Height x 9.5mm Width x 56mm Depth
- Maximum Connector Loss: 0.50 dB
- Typical Connector Loss: 0.30 dB
- Jacket Material: PVC (OFNR riser-rated)
- Jacket OD: 2.8 mm
- Maximum Tensile Load: 100 N/cm
- Impact Resistance: 1,000 cycles
- Flex Resistance: 5,000 cycles
- Attenuation at 1300 nm: 1.0 dB/km
- Attenuation at 850 nm: 3.5 dB/km
3.Fiber Optic Patch Cord Applications:
- CATV, LAN, WAN, Test &Measurement
- Fiber-optic communication networks
- Fiber Laser
- Telecommunication networks
- Data communication Broadband system
4.Specification&Technology Parameter
| Parameters | Value |
| Connector Type | LC/UPC,LC/UPC |
| Center Wavelength(nm) | 1310 or 1550 |
| Max.Insertion Loss(dB) | 0.3 |
| Min.Extinction Ratio(dB) | 23 |
| Min.Return Loss(UPC) (dB) | 50 |
| Min.Return Loss(APC) (dB) | 60 |
| Key Orientation | Slow Axis |
| Axis Alignment(deg) | ±3 |
| Operating Temperature(℃) | -20~+70 |
| Storage Temperature(℃) | -40~+85 |
| FIber Type | PM Panda Fiber |
* For Device with connector.IL is 0.3dB higher,RL is 5dB lower,ER
is 2dB lower.
* The default connector key is aligned to the slow axis.
5.LC to FC Connector Specification& Technology Parameter:
| Parameter | Unit | Index |
| End-Face Type | | PC | UPC | APC |
| IL | dB | SM: ≤0.3；MM ≤0.1 |
| Repeatability | dB | ≤0.1 |
| interchangeability | dB | ≤0.2 |
| RL | SM | dB | ≥50 | ≥50 | ≥50 |
| MM | dB | ≥36(Without APC connector) |
| Mating Times | | ＞1000 |
| Operating Temperature | ℃ | -40~ +80 |
6. MTRJ Connector Ordering Information:
- Connector Type: SC, LC,ST, FC, MTRJ, MU, MPO, MTP
- Ferrule end-face: PC, UPC or APC
- Fiber Type: Single Mode(SM) or Multimode(MM)
- Cable Core: Simplex or Duplex
- Cable Diameter: 0.9mm, 1.8mm, 2.0mm.2.8mm,3.0mm...
- Cable Length: 1, 2, 3 meter or customized
- Cable Type: PVC, LSZH, OFNR, OFNP…
- Cable color: Yellow, Orange, White, Blue, Green, Red...
- Standard: Telcordia GR-326-Core
- OEM Service: With many stock drawing for reference
